| Specification parameter | ||
| system | Main Processor | Dual-core 32-bit DSP (XM530V200/GK7020 V300), pure hard compression, watchdog |
| image sensor | High performance CMOS sensor | |
| Operation System | Embedded LINUX operating system | |
| Video Compression | Smart H.265X | |
| APP | Super Look (Android and IOS) | |
| Video | High Definition | 2MP/3MP/4MP |
| Image resolution | Main stream: 1920*1080/2304*1296/2560*1440@12fps; Substream: 800*448@12fps | |
| Minimum illumination | 0.01LUX/F1.2 | |
| Lens | 2.8mm | |
| Perspective | 92° | |
| Turn video | Upside down/Turn around | |
| lighting | Light control mode | Full Color/Smart/Infrared Night Vision |
| Number of lights | 4 PCS IR LED+4PCS lighting LED | |
| PTZ | PTZ control | Rotation Angle level :355°; Vertical: 90 ° |
| Turn PTZ | Upside down/Turn around | |
| Audio | Coding standard | G.711 |
| Mitou | Support | |
| Two-way Speech | Support | |
| Record management | Video file size | ≈6G/day |
| Record Mode | Manual record, motion detection record, scheduled record, alarm record | |
| Video storage | TF Card/Cloud | |
| storage | support TF card（max 128GB) or cloud storage | |
| Remote playback | Support | |
| Image capture | Support | |
| Network | WIFI | 2.4G WIFI 802.11b/g/n |
| Pairing | Sweep QR code，Network Cable connection，AP Hotspot Addition | |
| Network Protocol | Support TCP/IP, ONVIF, RTSP | |
| extension | Reset key | Support |
| Human tracking | Support | |
| 360degree coordinate positioning | Support | |
| power supply | Power | AC110-230V |
| power interfac | E27 | |
| work environment | Suitable place | outdoor、Home、shop、School、factory； |
| Installation mode | Wall mounted、hoisting | |
| Working Temperature | -20℃－＋55℃ | |
| Working humidity | 10%－90% | |
