| Model No. | |||
| Camera Type | Bullet IP Camera | ||
| System | Embedded RTOS design | ||
| Camera | Effective Pixels | 5.0 Mega Pixels | 8.0 Mega Pixels |
| Main stream:2592*1944 | Main stream: 2592*1944@25fps |
||
| Sub stream:704*576 | Sub stream:704*576 | ||
| Image Sensor | 1/2.8" SONY CMOS Sensor with ICR | 1/2.8" SONY CMOS Sensor with ICR | |
| 5 Megapixel resolution | 8 Megapixel resolution | ||
| (2616H*1964V) | (3840H*2160V) | ||
| DSP | Dual core 32-bit DSP | Dual core 32-bit DSP | |
| GK7205V300 | NT98566 | ||
| Min. Illumination | Color0.001Lux@F1.2 | ||
| B/W 0.0001 Lux@F1.2 | |||
| Adjust Parameters | DWDR,BLC,DNR,AE,AGC,D&N,Mirror,Flip,etc. | ||
| Video | Compression | H.265/H.264 Main profile | |
| Stream | support dual stream,AVI format | ||
| Bit Rate | support 0.1M ~8Mpbs bit rate adjustable | ||
| Frame Rates | support 1~30fps adjust | support 1~15fps adjust | |
| Audio | Input and output | ||
| Compression | G.711 compression,support two-way audio intercom,support audio and video synchronized output | ||
| Alarm | Types | Motion Detection, Video Blind , Video Loss | |
| Network | WEB Browser | Support WEB remote config( IE, Safari, Google Chrome, Firefox etc.) | |
| Smart Phone | mobile remote Monitoring (iPhone,Android,....) | ||
| CMS Software | Uniform CMS Software(multiple devices management system) | ||
| Cloud P2P | MYEYEplatform and other program,Offer SDK | ||
| Network | 1 * RJ45,10/100M,Support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/SMTP | ||
| ONVIF | Support (ONVIF 2.4) | ||
| POE | Support(optional) | ||
| WIFI | N/A | ||
| General | Language | 2 languages Such as English,Chinese. | |
| IR Cut Filter | Set of double light switch IR-CUT filter | ||
| Lens Mount | 4x Optical Motorized Zoom Autofocus Lens 2.8-12mm | ||
| Infrared Luminary | 8pcs Array IR LED | ||
| Infrare Wavelength | 850nm | ||
| Illuminate Distance | 40m | ||
| Waterproof Criterion | IP 66 | ||
| I/O Connector | 1*DC Connector ,1* RJ45(10/100M Network) | ||
| Supplied Voltage | DC12V/PoE(802.3af/820.3at) | ||
| Powe Consumption | IR On: 600mA max., IR Off: Less than 200mA | ||
| Workin Environment | -10°C~+60°C, 10%~90% ( Built in Heater being optional added for enviroment lower than -20° ) | ||
| Weight | 1.4kg | ||
